Xtreme Motorsport 200mm twin plate
The Xtreme 200mm Race Clutch was developed with a focus on those interested in a cost-effective alternative compared to other race style clutch kits on the market but without having to compromise on quality.The 200mm Race Clutch Kits consist of a Billet Flywheel, Solid-centered Ceramic Clutch Plates, Cover assembly, Thrust Bearing & Carrier / or the Internal Concentric Slave Cylinder (CSC). Product Features:
- Torque capacity 1200Nm
- Kit contains everything you need for a successful installation + accessories
- High torque sprung driven discs (common hub)
- Push type billet alloy cover
- 4140 Chromoly pressure & intermediate plates
- Hardened steel wear posts
- Low inertia
- Serviceable components
- SFI certified design
| Clamping Force | 1000kg |
| Torque Rating | 1200Nm |
| Bearing Contact Diameter | 44-52mm |
| Bearing Load (@ 48mm) | 218kg |
| Release Travel Required | 6mm |
| Assembly Mass (without flywheel) | 7.4kg |
| Disc Set Static Mass | 2.15kg |
| Friction Thickness New | 7mm (0.275") |
| Friction Thickness Worn | 6.48mm (0.255") |
Passar till:
- Mazda RX-7 1.3 (FC1032) 1988.01-1992.06 13B 1308 Petrol 110 kW 150 BHP (1988.01 - 1992.06)Mazda RX-7 1.3 Turbo (FC1032) 1989.03-1991.12 13B-MSP 1308 Petrol 147 kW 200 BHP (1989.03 - 1991.12)
Mazda RX-7 1.3 (FC3S. FC1031) 1985.11-1989.04 RE13B 1308 Petrol 110 kW 150 BHP (1985.11 - 1989.04)
Mazda RX-7 1.3 Turbo (FC3S. FC1031) 1987.06-1989.11 RE13B 1308 Petrol 133 kW 181 BHP (1987.06 - 1989.11)
Mazda RX-7 1.3 Turbo (FC3S. FC1031) 1989.03-1991.12 RE13B 1308 Petrol 147 kW 200 BHP (1989.03 - 1991.12)
