Xtreme Clutch 230mm twin plate kit
The Xtreme Clutch 230mm Race Clutch is available with either ceramic, organic or carbon friction materials, making these kits ideal for high horsepower and motorsport applications where a high heat capacity is required. The Xtreme 230mm Race Clutch is the ultimate in clutch solutions with a range like no other. The 230mm range boasts a variety of kits to suit most high horsepower applications for street, circuit, drift or race use. The Xtreme 230mm Race Clutch has been designed, allowing for endless options with clutch operation with internal hydraulic options and pull-push conversions a factoring feature in the 230mm range. Product Features:
- Torque capacity 1800Nm
- Kit contains everything you need for a successful installation + accessories
- Push type billet alloy cover Low pedal effort
- 4140 Chromoly pressure & intermediate plates
- Chromoly adapter ring
- Low inertia
- Serviceable components
- SFI certified design
| Flat Diaphragm | Rolled Diaphragm | |
| Clamping Force | 1300kg | 1300kg |
| Torque Rating | 1800Nm | 1800Nm |
| Bearing Contact Diameter | 65mm | FLAT BEARING |
| Bearing Load (@ 48mm) | 180kg | 150kg |
| Release Travel Required | 7mm | 7mm |
| Assembly Mass (without flywheel) | 8.30kg | 8.30kg |
| Disc Set Static Mass | 2.25kg | 2.25kg |
| Friction Thickness New | 8mm (0.315") | 8mm (0.315") |
| Friction Thickness Worn | 7.5mm (0.295") | 7.5mm (0.295") |
Passar till:
- BMW 5-Series E60 | 520i 2003-2010 2171cc | 125KW | 170HP | M54 B22 (226S1) (2003-2010)BMW 5-Series E60 | 525i 2003-2005 2494cc | 141KW | 192HP | M54 B25 (256S5) (2003-2005)
BMW 5-Series E61 | 525i 2004-2010 2494cc | 141KW | 192HP | M54 B25 (256S5) (2004-2010)
BMW 3-Series E46 | 330i 2001-2005 2979cc | 168KW | 228HP | M54 B30 (306S3) (2001-2005)
BMW 3-Series E46 | 330i 2000-2005 2979cc | 170KW | 231HP | M54 B30 (306S3) (2000-2005) 6 Speed, n - BMW 3-Series E46 | 330Xi 2000-2005 2979cc | 170KW | 231HP | M54 B30 (306S3) (2000-2005)
BMW X5 E53 | 3.0i 2000-2006 2979cc | 170KW | 231HP | M54 B30 (306S3) (2000-2006)
BMW 3-Series E46 | 330Ci 2000-2006 2979cc | 170KW | 231HP | M54 B30 (306S3) (2000-2006) 6 Speed, n - BMW 3-Series E46 | 330Xi 2000-2006 2979cc | 170KW | 231HP | M54 B30 (306S3) (2000-2006)
BMW 5-Series E60 | 530i 2001-2005 2979cc | 170KW | 231HP | M54 B30 (306S3) (2001-2005)
BMW X3 E83 | 3.0 i xDrive 2003-2006 2979cc | 170KW | 231HP | M54 B30 (306S3) (2003-2006)
