Xtreme Clutch 230mm twin plate kit
The Xtreme Clutch 230mm Race Clutch is available with either ceramic, organic or carbon friction materials, making these kits ideal for high horsepower and motorsport applications where a high heat capacity is required. The Xtreme 230mm Race Clutch is the ultimate in clutch solutions with a range like no other. The 230mm range boasts a variety of kits to suit most high horsepower applications for street, circuit, drift or race use. The Xtreme 230mm Race Clutch has been designed, allowing for endless options with clutch operation with internal hydraulic options and pull-push conversions a factoring feature in the 230mm range. Product Features:
- Torque capacity 1800Nm
- Kit contains everything you need for a successful installation + accessories
- Push type billet alloy cover Low pedal effort
- 4140 Chromoly pressure & intermediate plates
- Chromoly adapter ring
- Low inertia
- Serviceable components
- SFI certified design
| Flat Diaphragm | Rolled Diaphragm | |
| Clamping Force | 1300kg | 1300kg |
| Torque Rating | 1800Nm | 1800Nm |
| Bearing Contact Diameter | 65mm | FLAT BEARING |
| Bearing Load (@ 48mm) | 180kg | 150kg |
| Release Travel Required | 7mm | 7mm |
| Assembly Mass (without flywheel) | 8.30kg | 8.30kg |
| Disc Set Static Mass | 2.25kg | 2.25kg |
| Friction Thickness New | 8mm (0.315") | 8mm (0.315") |
| Friction Thickness Worn | 7.5mm (0.295") | 7.5mm (0.295") |
Passar till:
- Holden H Series VS | 5.0i V8 1995.08-1997.06 50LB9 4987 Petrol 165 kW 224 BHP (1995.08 - 1997.06)Holden H Series 5.0 i V8 1995.04-1999.06 50LB9 4987 Petrol 168 kW 228 BHP (1995.04 - 1999.06)
Holden H Series VS | 5.0i V8 1995.04-1999.06 50LB9 4987 Petrol 168 kW 228 BHP (1995.04 - 1999.06)
Holden H Series VS | 5.0i V8 1996.06-2000.12 50LB9 4987 Petrol 168 kW 228 BHP (1996.06 - 2000.12)
Holden H Series VS | 5.0i V8 1997.06-1997.09 50LB9 4987 Petrol 168 kW 228 BHP (1997.06 - 1997.09)
Holden H Series VT | 5.0 V8 1997.09-1999.06 50LB9 4987 Petrol 179 kW 243 BHP (1997.09 - 1999.06)
Holden H Series VT | 5.0i V8 1997.09-2002.08 50LB9 4987 Petrol 179 kW 243 BHP (1997.09 - 2002.08)
Holden H Series VT | 5.0i V8 1998.04-2000.08 50LB9 4987 Petrol 195 kW 265 BHP (1998.04 - 2000.08)
Holden H Series VT | 5.0 V8 1998.04-2000.10 50LB9 4987 Petrol 195 kW 265 BHP (1998.04 - 2000.10)
Holden H Series VS | 5.0i V8 1995.08-1997.06 GMH 308 4987 Petrol 165 kW 224 BHP (1995.08 - 1997.06)
Holden H Series VS | 5.0i V8 1997.06-1997.09 GMH 308 4987 Petrol 168 kW 228 BHP (1997.06 - 1997.09)
HSV Clubsport VS | 5.0i V8 1995.04-1997.08 GMH308 4987 Petrol 185 kW 252 BHP (1995.04 - 1997.08)
HSV Clubsport VT | 5.0i V8 1997.01-1999.06 GMH308 4987 Petrol 195 kW 265 BHP (1997.01 - 1999.06)
HSV Manta VS | 5.0i V8 1995.04-1997.08 VU 4987 Petrol 185 kW 252 BHP (1995.04 - 1997.08)
HSV Senator VS | 5.0i V8 1995.04-1997.08 VU 4987 Petrol 185 kW 252 BHP (1995.04 - 1997.08)
HSV Maloo VS | 5.0i V8 1995.04-1999.05 VU 4987 Petrol 185 kW 252 BHP (1995.04 - 1999.05)
HSV Maloo VS | 5.0i V8 1995.05-2000.10 VU 4987 Petrol 195 kW 265 BHP (1995.05 - 2000.10)
HSV Manta VT | 5.0i V8 1997.09-1999.01 VU 4987 Petrol 195 kW 265 BHP (1997.09 - 1999.01)
HSV Senator VT | 5.0i V8 1997.09-2000.08 VU 4987 Petrol 195 kW 265 BHP (1997.09 - 2000.08)
HSV XU8 VT | 5.0i V8 1999.01-1999.06 VU 4987 Petrol 195 kW 265 BHP (1999.01 - 1999.06)
