Xtreme Motorsport 200mm twin plate
The Xtreme 200mm Race Clutch was developed with a focus on those interested in a cost-effective alternative compared to other race style clutch kits on the market but without having to compromise on quality.The 200mm Race Clutch Kits consist of a Billet Flywheel, Solid-centered Ceramic Clutch Plates, Cover assembly, Thrust Bearing & Carrier / or the Internal Concentric Slave Cylinder (CSC). Product Features:
- Torque capacity 1200Nm
- Kit contains everything you need for a successful installation + accessories
- High torque sprung driven discs (common hub)
- Push type billet alloy cover
- 4140 Chromoly pressure & intermediate plates
- Hardened steel wear posts
- Low inertia
- Serviceable components
- SFI certified design
| Clamping Force | 1000kg |
| Torque Rating | 1200Nm |
| Bearing Contact Diameter | 44-52mm |
| Bearing Load (@ 48mm) | 218kg |
| Release Travel Required | 6mm |
| Assembly Mass (without flywheel) | 7.4kg |
| Disc Set Static Mass | 2.15kg |
| Friction Thickness New | 7mm (0.275") |
| Friction Thickness Worn | 6.48mm (0.255") |
Passar till:
- Mazda 626 2.0 i (GE10S1) 1991.08-1997.04 FS 1991 Petrol 85 kW 115 BHP (1991.08 - 1997.04)Mazda 626 2.0 i (GE10S1) 1992.01-1997.04 FS 1991 Petrol 85 kW 115 BHP (1992.01 - 1997.04)
Mazda 626 2.0 GLX (GV) 1992.04-1995.02 FS 1991 Petrol 86 kW 117 BHP (1992.04 - 1995.02)
Mazda 626 2.0 (GF) 1998.01-2002.10 FS 1991 Petrol 93 kW 126 BHP (1998.01 - 2002.10)
Mazda 626 2.0 (GW) 1998.01-2002.10 FS 1991 Petrol 93 kW 126 BHP (1998.01 - 2002.10)
Mazda 323 2.0 (BJ) 2000.02-2004.05 FS 1991 Petrol 98 kW 133 BHP (2000.02 - 2004.05)
Mazda 323 2.0 (SP20) 2000.02-2004.05 FS 1991 Petrol 98 kW 133 BHP (2000.02 - 2004.05)
Mazda 323 2.0 (BJFW) 2001.01-2004.05 FS7E, FS7G 1991 Petrol 96 kW 131 BHP (2001.01 - 2004.05)
