Xtreme Motorsport 200mm twin plate
The Xtreme 200mm Race Clutch was developed with a focus on those interested in a cost-effective alternative compared to other race style clutch kits on the market but without having to compromise on quality.The 200mm Race Clutch Kits consist of a Billet Flywheel, Solid-centered Ceramic Clutch Plates, Cover assembly, Thrust Bearing & Carrier / or the Internal Concentric Slave Cylinder (CSC). Product Features:
- Torque capacity 1200Nm
- Kit contains everything you need for a successful installation + accessories
- High torque sprung driven discs (common hub)
- Push type billet alloy cover
- 4140 Chromoly pressure & intermediate plates
- Hardened steel wear posts
- Low inertia
- Serviceable components
- SFI certified design
| Clamping Force | 1000kg |
| Torque Rating | 1200Nm |
| Bearing Contact Diameter | 44-52mm |
| Bearing Load (@ 48mm) | 218kg |
| Release Travel Required | 6mm |
| Assembly Mass (without flywheel) | 7.4kg |
| Disc Set Static Mass | 2.15kg |
| Friction Thickness New | 7mm (0.275") |
| Friction Thickness Worn | 6.48mm (0.255") |
Passar till:
- Nissan Almera Tino 2.0 2000.08-2003.01 SR20DE 1998 Petrol 100 kW 136 BHP (2000.08 - 2003.01)Nissan Sunny N14 | 2.0 1990.08-1996.12 SR20DE 1998 Petrol 104 kW 141 BHP (1990.08 - 1996.12)
Nissan Sunny N14 | 2.0 GTI 16V 1990.10-1995.05 SR20DE 1998 Petrol 105 kW 143 BHP (1990.10 - 1995.05)
Nissan Sunny N14 | 2.0 i 16V 1990.10-1995.05 SR20DE 1998 Petrol 105 kW 143 BHP (1990.10 - 1995.05)
Nissan 100NX 2.0 GTI (B13) 1991.03-1994.10 SR20DE 1998 Petrol 105 kW 143 BHP (1991.03 - 1994.10)
Nissan Sunny N14 | 2.0 1991.10-1993.05 SR20DE 1998 Petrol 105 kW 143 BHP (1991.10 - 1993.05)
Nissan Primera P11 | 2.0 16V 1996.06-2001.12 SR20DE 1998 Petrol 105 kW 143 BHP (1996.06 - 2001.12)
Nissan Almera 2.0 GTi (N15) 1996.07-2000.03 SR20DE 1998 Petrol 105 kW 143 BHP (1996.07 - 2000.03)
Nissan 100NX 2.0 (B13) 1990.10-1994.10 SR20DE 1998 Petrol 110 kW 150 BHP (1990.10 - 1994.10)
Nissan Primera P11 | 2.0 16V 1996.09-2002.07 SR20DE 1998 Petrol 110 kW 150 BHP (1996.09 - 2002.07)
Nissan Primera P11 | 2.0 16V 1996.09-2002.07 SR20De 1998 Petrol 85 kW 115 BHP (1996.09 - 2002.07)
Nissan Primera P11 | 2.0 16V 1996.09-2002.07 SR20DE 1998 Petrol 96 kW 131 BHP (1996.09 - 2002.07)
